PT | How to Approach Advent of Code 2024 Day 21 Problem?

Advent of Code 2024 was a really interesting one, the variety of problems was wider than the ones in previous editions. Also, it was the first AoC challenge I completed to the end and earned 50 stars. Among all the problems, I found the problem on Day 21 most challenging. therefore, I am writing this detailing my approach to solving this problem.

What the problem asks

To put it mathematically, The problem gives multiple layers. and at each layer a the input of previous layer is transformed (expanded) and this expanded output is the input for another layer. But, there can be multiple expansions that are valid. and the goal is to find the length of smallest valid transformation.

generic psuedocode

class Input: ...

def expand(i: Input) -> set(Input): ...

res: set[Input] = set(Input(...))
for _ in range(LAYERS):
    next_res = set()
    for i in res:
        next_res |= expand(i)

    res = next_res

return min(len(i) for i in res)

Understanding the “Rules of Expansion”

In the first part of the problem, it is given that there are 3 robots controlling the one infront of it, As shown in diagram below:

P1 Diagram

And each robot is typing into the keypad infront of it. And here is how each one is controlled:

Each robot’s arm is initially at A button.
Each robot needs to be provided with the exact instructions to move its arm as follows:
- ^: move arm 1 key up
- >: move arm 1 key right
- <: move arm 1 key left
- v: move arm 1 key down
- A: press the key under the arm
Arm cannot move over the hole or blank space

FinBot is controlling numeric keypad as shown below:

+---+---+---+
| 7 | 8 | 9 |
+---+---+---+
| 4 | 5 | 6 |
+---+---+---+
| 1 | 2 | 3 |
+---+---+---+
    | 0 | A |
    +---+---+

Whereas other bots are controlling directional keypad:

    +---+---+
    | ^ | A |
+---+---+---+
| < | v | > |
+---+---+---+

From the given rules, we can start working on expand function:

Lets say the FinBot wants to type in 540A,

To do this, the arm of FinBot should reach the keys in following order: A - 5 - 4 - 0 - A.

Now, Lets take the first step: going A - 5:

the key 5 is 1 step left and 2 step above the key A. So, given that the arm can move only in 4 directions, The least number of steps required will be equal to the Manhattan Distance between the two.

Any other path taken will always contain 2 Up and 1 Left. So, I can safely eliminate the paths that are more than 3 steps. This can be proven mathematically by Graph Theory. But one can also understand it intuitively using Vectors.

improvised pseudocode for part 1

Now that we know the exact rules we can improvise our original psuedocode:

class Keypad(): ...

numeric_keypad = Keypad(...)
directional_keypad = Keypad(...)

def expand(i: str, keypad: Keypad) -> set[str]: ...

res: set[str] = expand("313A", numeric_keypad)
for _ in range(3):
    next_res = set()
    for i in res:
        next_res |= expand(i, directional_keypad)

    res = next_res

return min(len(i) for i in res)

Finding the shortest route

The shortest signal the MidBot sends has to be combination of 2 Up and 1 Left and A at the end to press the button: <^^A, ^^<A or^<^A.

For a moment, lets not consider the rule 3. Can one eliminate something among these?

Maybe one can? Lets first consider the set of motions that MidBot needs to do for all three shortlisted options:

^^<A: A to ^ - Press Twice - ^ to < - Press Once - < to A - Press Once
<^^A: A to < - Press Once - < to ^ - Press Twice - ^ to A - Press Once
^<^A: A to ^ - Press Once - ^ to < - Press Once - < to ^ - Press Once - ^ to A - Press Once

Wait! If you observe carefully, the motions of option 3 contains motion of both option 1 and 2! that means motions of option 3 is superset of both option 1 and option 2.

To first understand why option 3 is superset. One needs to recognize:

Motions are reversible.

The motion from A to < has the same steps as < to A. just in reverse order.

and given that to reach from any keyx to key y requires movement in only 2 direction: Horizontal and Vertical any motion can be divided into few sets of motion.

In this case, all the possible motions are composed of following 3 sets of sub motion:

motion(A, <)
motion(A, ^)
motion(<, ^)

In the best case scenario, all the 3 required motions will be used only once. and in any other case, a set of motion will be repeated.

If we observe, in case 1 and 2, the keys are grouped together and therefore need to move only once from directional key to another directional key. whereas in option 3 motion(<,^) is required twice. And this is true irrespective of shape of keypad.

This tells us something important:

If a grouped path exists, then it will be subset of all ungrouped ones and thus the shorter one.

With this knowledge one can simplify choices to following:

Move Vertically, then Move Horizontally
Move Horizontally, then Move Vertically

further, if any of the Input requires robot to move its arm over the hole then that option can be eliminated.

For part 1, I simply did brute force expansion. and found the minimum length among all the valid solutions. While this naive approach worked for part 1. in part 2 there are 25 robots in chain! and seeing that the solution expands exponentially (napkin math says length of solution is approx k*2^n, where k is length of initial Input and n is number of layers).

Dynamic Programming Solution

Brute force was not going to work for Part 2. I would need super computer to work with strings that large.

Reducing Information

But wait! This problem only asked me to find length of smallest string, not the exact string. This could mean:

I am storing and working with more information than needed.

This means, the result of each transformation doesn’t need to be set of entire strings. strings contain a lot of information that is unnecessary to solve this problem.

Consider 3 robots in chain A, B, C. A possible control signals of these robots following the established rules are given below:

A: 540
B: (^^<A | <A | >vvA)
C: (<A | A | v<A | >>^A) | (v<<A | >>^A) | (vA | <A | A | ^>A)

Consider the expansion of first character 5 :: ^^<A :: <A | A | v<A | >>^A.

Lets see where the arms of each robot is initially and after the key 5 is pressed by robot A:

A: A -> 5
B: A -> A
C: A -> A

Observe that after each key press of Robot A, the arms of robot B returns back to the key where it started. And similarly after every character of robot B arms of C return back. Since the rules are symmetric for all layers, this pattern will continue forever.

Now, when we are computing expansion of next character of Robot A ie. 4, the arm of all the robots above in the chain are already on their home key A, as if they had never moved before.

This means, expansion of a chunk of command by B like ^^<A is dependent only in itself. Not what comes before it or after it. This implies:

Cost of executing chunk of command is dependent only on itself.

Combining the above disovery with the fact that addition is an Commutative property, all we need to store is a map or dict of chunk and no. of times it occurs. This provides enough data for next layer to expand upon.

Computing Expansions

The directional keypad that robots are controlling is very small, with height of 2 keys and width of 3. which means, any chunk consist of following: 0-1 step vertically and / or 0-2 steps horizontally + ending A

And after removing duplicates, we are left with only 23 possible chunks as follows:

"A", ">A", ">^A", ">vA", "^>A", "v>A", ">>A", "^>>A", "v>>A", ">>^A", ">>vA",
"<A", "<^A", "^<A", "v<A", "<vA", "<<A", "^<<A", "v<<A", "<<^A", "<<vA", "^",
"v"

Entire command is just combination of these 23 small chunks Irrespective of at which layer the robot is sitting.

In my approach, I first precomputed optimal expansions and hardcoded those in the source code of my program.

I did some permutation and combination and realized that expanding each chunk twice gave me a clear answer for which expansion was the most optimal. While I do not have definite “math” for why it works. But I believe it works because, expanding twice is enough to give me expansions of different length.

Here is the code I used to find the expansions, Its not the best but its readable enough.

improvised pseudocode

type Command = dict[str, int]

class Keypad(): ...

numeric_keypad = Keypad(...)
directional_keypad = Keypad(...)

# hardcode pre-computed expansions in this function
def expand(i: Command, keypad: Keypad) -> Command: ...

def cost(i: command) -> int: ...

res: Command = expand({"313A": 1}, numeric_keypad)
for _ in range(25):
    res = expand(res)

return cost(res)

And the last part is generating a new Command at each layer using pre computed expansions and then calculate the Cost of the Command we arrive at after N layers.

Here is my solution I used to solve this problem: code

This approach solves P2 in just few ms in my go solution. and perhaps it can solve the problem with way more layers. but at that point you should be more worried about hitting limits of int64.

Big O Notation

Each expansion step operates over a map whose maximum size is 23 for the given keypad. which is practically constant time. expand function is called once at every layer so the big O notation is: O(L)

where, L = No. of Layers

Conclusion

While part 2 of the problem looks difficult on surface, it can be easily tackled by breaking it down and getting rid of the information that is unneeded and working with least information required to find the length of solution.

Tscheus!
